Panel size

1 x 0.55”

Brightness

3500 ANSI Lumens

Contrast ratio

15000:1

Native resolution

XGA (1024 x 768)

Lens

F = 2.51 – 2.69, f = 21.95mm – 24.18mm, 1.1x, Manual focus lens

Throw ratio

1.97 – 2.17 : 1

Uniformity

80%

Projection distance

1.2m – 11m (3.93ft – 36.1ft)

Screen size (diagonal)

0.68m – 7.36m (27” – 300”)

Aspect ratio

4:3 (Standard), 16:9 (Compatible)

Lamp

1 x 203 Watts

Lamp life

4,500 hours (Std), 6,000 hours (Eco), 10,000 hours (Dynamic Eco)

Keystone correction range

Vertical: ±40° (Manual)

Installation method

Ceiling/floor, front/rear

Terminals

HDMI IN

HDMI IN

MHL

N/A

COMPUTER IN 1

D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR/S-VIDEO)

COMPUTER IN 2

N/A

COMPOSITE VIDEO

N/A

S-VIDEO

N/A

COMPONENT VIDEO

N/A

MIC IN

N/A

AUDIO 1 IN

Pin jack x 1

AUDIO 2 IN

N/A

LAN

N/A

USB A

N/A

USB B

N/A

Mini USB

Firmware upgrade

MONITOR OUT

N/A

AUDIO OUT

M3 x 1 (L-R x 1) for output (variable)

RS-232C

9-pin (male) x 1

12V TRIGGER

N/A

PC compatibility

VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac

Video compatibility

PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i

Power supply

AC 100-240 V, 50/60 Hz

Power consumption

Max. 260W / Std. 245W / Eco. 220W

Built-in speaker

2 W (monaural)

Noise level

32 dB (lamp control: Normal), 28 dB (lamp control: Eco)

Cabinet materials

Molded plastic (PC)

Dimensions (W x H x D)

28.5 x 19.3 x 11.1cm (11.2” x 7.6” x 4.4”)

Net weight

1.97Kg (4.32Lbs)

Operating temperature

0°C - 40°C

Storage temperature

-20°C - 60°C

OSD languages

English, German, French, Italian, Spanish, Polish, Swedish, Portuguese, Japanese, Arabic, Dutch, Simplified Chinese, Traditional Chinese, Korean, Russian, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Persian

Standard accessories

User manual (CD), Power cord, Remote control, VGA cable

Optional accessories

Replacement lamp module, HDMI cable, Screen, Bracket
