LCD panel | Display technology | Transparent LCD panel (x 3, R/G/B) |
|
Panel size | 3 x 0.63" |
|
Brightness |
| 5600 ANSI Lumens |
|
Contrast ratio | 10000:1 |
|
Native resolution | XGA (1024 x 768) |
|
Lens | F = 1.6 - 2.08, f = 19.36 - 31.94mm, 1.65x, V. ±40° (Manual) H. ±10° (Manual) |
|
Throw ratio |
| 1.48 - 2.47 : 1 |
|
Uniformity | 90% |
|
Projection distance | 1.0m - 14.0m |
|
Screen size (diagonal) | 40” - 300” |
|
Aspect ratio | 4:3 (Standard), 16:9 (Compatible) |
|
Lamp | 1 x 280 Watts |
|
Lamp life | (STD Mode) 4000 hours, (ECO Mode) 6000 hours |
|
Keystone correction range | Vertical: ±30° (Auto/Manual) Horizontal: ±15° (Manual), Corner Keystone |
|
Installation method | Ceiling/floor, front/rear |
|
Terminals | HDMI IN | HDMI IN |
|
MHL | N/A |
|
COMPUTER IN 1 | D-sub HD 15-pin (female) x 1 |
|
COMPUTER IN 2 | D-sub HD 15-pin (female) x 1 |
|
COMPOSITE VIDEO | Share with COMPUTER IN 1 |
|
S-VIDEO | Share with COMPUTER IN 1 |
|
COMPONENT VIDEO | Pin jack x 3 |
|
MIC IN | N/A |
|
AUDIO 1 IN | M3 x 1 (L-R x 1) |
|
AUDIO 2 IN | Pin jack x 2 (L, R x 1) |
|
LAN | RJ-45 x 1
(for control and display, 10BASE-T/100BASE-TX) |
|
USB A | USB type-A (for the Memory Viewer/Wireless Module) x 1 |
|
USB B | USB type-B (for the USB Display) x 1 |
|
Mini USB | N/A |
|
MONITOR OUT | D-sub HD 15-pin (female) x 1 (RGB, Monitor output, share with COMPUTER IN 1) |
|
AUDIO OUT | M3 x 1 (L-R x 1) for output (variable) |
|
RS-232C | 9-pin (male) x 1 |
|
12V TRIGGER | N/A |
|
PC compatibility | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
|
Video compatibility | PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i |
|
Power supply | AC 100-240 V, 50/60 Hz |
|
Power consumption | 320 Watts |
|
Built-in speaker | 10 W (monaural) |
|
Noise level | 37 dB (lamp control: Normal), 33 dB (lamp control: Eco) |
|
Cabinet materials | Molded plastic (PC) |
|
Dimensions (W x H x D) | 15.2” x 12.1” x 4.3” |
|
Net weight | Approximately 4.8Kg (10.7Lbs) |
|
Operating temperature | 0°C - 40°C (Over 35°C Go to ECO Mode) |
|
Storage temperature | -20°C - 60°C |
|
OSD languages | English, German, French, Italian, Spanish, Polish, Swedish, Portuguese, Japanese, Arabic, Dutch, Simplified Chinese, Traditional Chinese, Korean, Russian, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Persian |
|
|
|
Standard accessories | User manual (CD), Power cord, Remote control, VGA cable |
|
Optional accessories | Replacement lamp module, WiFi display module, HDMI cable, Screen, Bracket |
|
