DLP panel | Display technology | Single DLP® Technology by Texas Instruments |
|
Panel size | 1 x 0.55” |
|
Brightness | | 3200 ANSI Lumens |
|
Contrast ratio | 5000:1 |
|
Native resolution | XGA (1024 x 768) |
|
Lens | F = 2.51 – 2.69, f = 21.95mm – 24.18mm, Fixed zoom, Manual focus lens |
|
Throw ratio | 0.61 : 1 |
|
Uniformity | 80% |
|
Projection distance | 0.5m – 4.0m (1.64ft – 13.12ft) |
|
Screen size (diagonal) | 0.94m – 7.36m (37” – 300”) |
|
Aspect ratio | 4:3 (Standard), 16:9 (Compatible) |
|
Lamp | 1 |
|
Lamp life | 4,500 hours (Std), 6,000 hours (Eco) |
|
Keystone correction range | Vertical: ±40° (Manual) |
|
Installation method | Ceiling/floor, front/rear |
|
Terminals | HDMI IN | HDMI IN |
|
MHL | N/A |
|
COMPUTER IN 1 | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|
COMPUTER IN 2 | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|
COMPOSITE VIDEO | Pin jack x 1 |
|
S-VIDEO | Pin jack x 1 |
|
COMPONENT VIDEO | N/A |
|
MIC IN | Pin jack x 1 |
|
AUDIO 1 IN | Pin jack x 1 |
|
AUDIO 2 IN | N/A |
|
LAN | N/A |
|
USB A | N/A |
|
USB B | N/A |
|
Mini USB | Firmware upgrade |
|
MONITOR OUT | D-sub HD 15-pin (female) x 1 |
|
AUDIO OUT | Pin jack x 1 |
|
RS-232C | 9-pin (male) x 1 |
|
12V TRIGGER | N/A |
|
PC compatibility | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
|
Video compatibility | PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i |
|
Power supply | AC 100-240 V, 50/60 Hz |
|
Power consumption | Std. 350W / Eco. 280W |
|
Built-in speaker | 2 W (monaural) |
|
Noise level | 32 dB (lamp control: Normal), 30 dB (lamp control: Eco) |
|
Cabinet materials | Molded plastic (PC) |
|
Dimensions (W x H x D) | 28.4 x 23.4 x 8.8cm (11.2” x 9.2” x 3.5”) |
|
Net weight | 2.6Kgs (5.7Lbs) |
|
Operating temperature | 0°C - 40°C |
|
Storage temperature | -20°C - 60°C |
|
OSD languages | English, German, French, Italian, Spanish, Polish, Swedish, Portuguese, Japanese, Arabic, Dutch, Simplified Chinese, Traditional Chinese, Korean, Russian, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Persian |
|
|
|
Standard accessories | User manual (CD), Power cord, Remote control, VGA cable |
|
Optional accessories | Replacement lamp module, HDMI cable, Screen, Bracket |
|
