LCD panel | Display technology | Transparent LCD panel (x 3, R/G/B) |
|
Panel size | 3 x 0.76" |
|
Brightness | | 5600 ANSI Lumens |
|
Contrast ratio | 5000:1 |
|
Native resolution | WUXGA (1920 x 1200) |
|
Lens | F = 1.8 - 2.6, f = 24.0 - 43.2mm, 1.8x, Vertical: ±60° (Powered) Horizontal: ±30° (Powered) |
|
Throw ratio | | 1.44 - 2.60 : 1 |
|
Uniformity | 90% |
|
Projection distance | 0.6m - 46.5m (Depanding on optional lenses) |
|
Screen size (diagonal) | 40” - 300” |
|
Aspect ratio | 4:3 (Compatible), 16:10 (Standard) |
|
Lamp | 1 x 350 Watts |
|
Lamp life | (STD Mode) 4000 hours, (ECO Mode) 6000 hours |
|
Keystone correction range | Vertical: ±15° (Auto/Manual) Horizontal: ±15° (Manual), Corner Keystone |
|
Installation method | Ceiling/floor, front/rear |
|
Terminals | HDMI IN | HDMI IN |
|
MHL | HDMI IN MHL |
|
COMPUTER IN 1 | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR/S-VIDEO) |
|
COMPUTER IN 2 | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR/S-VIDEO) |
|
COMPOSITE VIDEO | Share with COMPUTER IN 1 |
|
S-VIDEO | Share with COMPUTER IN 1 |
|
COMPONENT VIDEO | Share with COMPUTER IN 1 |
|
MIC IN | N/A |
|
BNC | Pin jack x 5 |
|
DVI-D | D-sub HD 24+1-pin (female) |
|
AUDIO 1 IN | M3 x 1 (L-R x 1) |
|
AUDIO 2 IN | Pin jack x 2 (L, R x 1) |
|
LAN | RJ-45 x 1
(for control and display, 10BASE-T/100BASE-TX, compliant with PJLink™/AMX/Crestron) |
|
USB A | USB type-A (for the Memory Viewer/Wireless Module) x 1 |
|
USB B | USB type-B (for the USB Display) x 1 |
|
Mini USB | Firmware upgrade |
|
MONITOR OUT | D-sub HD 15-pin (female) x 1 (RGB, Monitor output, share with COMPUTER IN 1) |
|
AUDIO OUT | M3 x 1 (L-R x 1) for output (variable) |
|
RS-232C | 9-pin (male) x 1 |
|
12V TRIGGER | N/A |
|
PC compatibility | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
|
Video compatibility | PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i |
|
Power supply | AC 100-240 V, 50/60 Hz |
|
Power consumption | 480 Watts |
|
Built-in speaker | 10 W (monaural) |
|
Noise level | 36 dB (lamp control: Normal), 32 dB (lamp control: Eco) |
|
Cabinet materials | Molded plastic (PC) |
|
Dimensions (W x H x D) | 48.0cm x 18.0cm x 42.0 cm (18.8” x 7.0” x 16.5”) |
|
Net weight | Approximately 9.9kg (21.8Lbs) |
|
Operating temperature | 0°C - 40°C (Over 35°C Go to ECO Mode) |
|
Storage temperature | -20°C - 60°C |
|
OSD languages | Simplified Chinese, English, French, Spanish, Portuguese, German, Italian, Japanese, Korean, Russian, Finnish, Dutch, Thai, Vietnamese, Turkey, Afrikaans, Indonesian, Persian, Arabic |
|
|
Standard accessories | User manual (CD), Power cord, Remote control, VGA cable |
|
Optional accessories | Optional Lenses, Replacement lamp module, WiFi display module, HDMI cable, Screen, Bracket |
|
